Optical Power Meter | MM 850/1300 | MT-7802

Product Code MT08822
Remaining Stock 0
To View the Price, Please Contact Us.
Alarm Icon Heart icon
  • Features
  • Documents
  • Comments (0)
  • Request for Quote
  • Optical Power Meter | MM 850/1300 | MT-7802


    MT-7802 fiber optic power meter supports multi-mode fibers with two wavelengths 850 and 1300; and it is ideal for fiber optic network installation and maintenance.

    • Built-in optic isolator, larger and more stable compared to desktop source.
    • Supports SC/PC connectors
    • LCD display with Backlight
    • Encodes each wavelength with a unique WaveID code
    • 3 detection modulations 270Hz, 1KHz, 2KHz
    • Easy Operation with wavelength switch
    • Works with DC 5v power or AA batteries
    • User friendly
    Fiber Optic MT-78 Power Meters Comparison
    Model no. MT-7801 MT-7802 MT-7803
    Wavelength 1310/1550nm±10nm 850/1300nm±10nm 1310/1490/1550nm±10nm
    Power Stability ±0.05dB / 1hr;±0.1dB / 8hrs
    output Power >-5dBm >-10dBm >-5dBm
    OPTIC connector SC/PC
    Modulation 270Hz, 1kHz,2kHz
    Auto power off 10 minutes (could be reset)
    Battery Charge Yes (when using rechargeable battery), by DC 5V power jack
    Low battery indication Yes
    Storage temperature -20~+70°C; <90%RH
    Operating temperature -10~+60°C; <90%RH
    Power source 2 x 1.5V AA batteries (not included)
    Dimension 165× 80 × 35mm
    Weight 280g
    package Color box
